Long range reader
Features
- Long range reader
- Support 125KHz & 433.9MHz
Specifications
| Model No. | PFH-9210-60 | PFH-9210-620 |
|---|---|---|
| Frequency | 125KHz ASK | 125KHz ASK & 433.9MHz |
| Compatibility | ISO18000-2 EM4001, 4100, 4102, TEMIC 5567 | ISO18000-2 EM4001, 4100, 4102, TEMIC 5567 RF Hand Free card |
| Reading Range | Max: 50-60cm | Max: 6M |
| Power Voltage | DC12V | DC15V |
| Output Format Interface | Wiegand / RS232 / RS485 | Wiegand / RS232 / RS485 / ABA |
| IP Rating | IP54 | |
| Dimensions (LxWxH)mm | 273x270x39 | |
Dimension: Unit(mm)
Optional accessory
The bracket for PFH-9210 series : PGV-BRACKET/205N
Vehicle loop detector:PK-PD-232
IR Sensor:LK-12HD
Ordering information
| PFH-9210-60-1/R2 | 125KHz RFID reader, with epoxy,RS-232 |
|---|---|
| PFH-9210-60-1/R5 | 125KHz RFID reader, with epoxy,RS-485 |
| PFH-9210-60-1/W | 125KHz RFID reader, with epoxy,Wiegand |
| PFH-9210-60-1A | 125KHz RFID reader, with epoxy,ABA |
We reserve the right to change the specification without prior notice or obligation!
Download
| # | Name | Upload Date | Description | Download |
|---|---|---|---|---|
1 | PFH-9210 | 2024-03-28 | Long range reader catalog |
