Handheld UHF 868MHz, 928MHz RFID & License Plate Collector
Features
- Download the data thru. USB interface and then generate the report by the software.
- Battery embedded, convince to use anywhere.
- One-touch operation: pressing a button for reading card.
- Compatible with ISO-18000-6C.
- Protocol comply with UHF EPC Gen2(ISO18000-6C) standard.
- Scan and save UHF label / card UID.
- Support license plate number input.
- Storage tags by EPC or TID code (selectable)
Specifications
| Dimensions | 151 (L) x 62 (W) x 34 (H) mm |
|---|---|
| Interface | USB / Bluetooth(Optional) |
| Reading range | Max.8cm(Depending on UHF label) |
| Antenna gain | 3dbi |
| Built-in RF module | 12dBM |
| Operating temperature | -10℃ ~ 75℃ |
| Storage temperature | -10℃ ~ 85℃ |
| Power supply | USB 5V / 3.7V(Lithium Battery) |
| RFID frequency | 860~928MHz |
| Events | 1,000 / 32,000(Optional) |
| Stand-by time | 20 hours |
Dimension
Accessories
Protective Case
- Model No. : R-26-350-4
- Material : Silicone
- Color : Cadet Green
Ordering information
| PHU-350 | Handheld UHF 868MHz, 928MHz RFID & License Plate Collector，USB |
| PHU-350B | Handheld UHF 868MHz, 928MHz RFID & License Plate Collector，USB / Bluetooth |
We reserve the right to change the specification without prior notice or obligation!
Download
| # | Name | Upload Date | Description | Download |
|---|---|---|---|---|
1 | PPT-350SWL | 2025-09-12 | Handheld UHF RFID & License Plate Collector Catalog |
