Model：PGS-703PGS-704
Fail Secure / Fail Safe Electric Strike
Compare
Product
Features
- Fail Secure / Fail Safe Electric type
- Support door monitoring switch
- All metal construction, safe and durable
- Suitable for Aluminum door, iron door, copper sulfide door, wooden door
Dimension: mm
Accessories
| Model No. | MK-738 |
|---|---|
| Dimensions(LxWxD)mm | 130x24.5x50 |
| Approx. weight | 690g±1% |
| Features | Pair with latch bolt lock. Could be released by key or knob. (By key: MK-738-1(optional) |
| Applications | For Aluminum door, iron door, copper sulfide door |
| Door thickness | 40~50mm |
Ordering information
| PGS-703 | Fail secured type Electric Strike, DC 12V |
|---|---|
| PGS-703-24V | Fail secured type Electric Strike, DC 24V |
| PGS-704 | Fail safe type Electric Strike, DC 12V |
| PGS-704-24V | Fail safe type Electric Strike, DC 24V |
We reserve the right to change the specification without prior notice or obligation!
Specification
Voltage /Current
DC12V (120mA) / DC24V (60mA)
DOOR MONITORING SWITCH
YES
Lock body
Zinc alloy
Keeper
Stainless steel
Net Weight (g)
420g±1%
PGS-703-24V
PGS-704-24V
LATCH BOLT
Up to 15mm
Download
※ The specifications listed are subject to change by the company. If they differ from the actual product, the actual product shall prevail.
