Model：PP-87
Multi-functional Standalone controller
Product
Features
- Classic and popular multi-functional Standalone controller
- Support 2000 Cards, PP-87VX:32,000 Card (Standalone)
- Built-in LED and Buzzer indicator
- Built-in Form A Relay
Specification
| Model No. | PP-87P-6D-K | PP-87N-6D-K PP-87VX/N |
PP-87/M0-6D-K PP-87VXM0 |
PP-87M3 |
| Frequency | 125 KHz ASK | 125 KHz ASK | 13.56 MHz | Applied with Anti-duplicate card |
| Compatibility | ISO18000-2 EM4001, 4100, 4102, Pegasus Format | ISO18000-2 EM4001, 4100, 4102, TEMIC 5567 | ISO14443 A, MIFARE® Classic, Plus, Ultralight, DESFire, NFC (card simulation) | |
| User Capacity | 2000 (PP-87VX series: 32000) | |||
| Power Voltage | DC 12V | |||
| Input | Exit push button / Door monitor / Security sensor | |||
| Output | Alarm output / Tamper switch output / Electric lock output | |||
| Keypad | Plastic | |||
| Material | ABS | |||
| Dimensions (L x W x H) | 116 x 81 x 30 mm | |||
| IP Rating | IP54 | |||
System configuration
Mifare is a registered trademark of NXP B.V.
Mifare DESFire is a registered trademark of NXP B.V.
Mifare Ultralight is a registered trademark of NXP B.V.
We reserve the right to change the specification without prior notice or obligation!
Specification
Model No
PP-87
Compatibility
ISO18000-2 EM4001, 4100, 4102, Pegasus 格式(PP-87P-6D-K) / ISO18000-2 EM4001, 4100, 4102, TEMIC 5567(PP-87N-6D-K) / ISO14443 A, MIFARE® Classic, Plus, Ultralight, DESFire, NFC Ntag213/215/216(PP-87/M0-6D-K) / Applied with Anti-duplicate card(PP-87M3)
Dimensions (L x W x D) mm
116 x 81 x 30
Keypad
Plastic
Output
Alarm output / Tamper switch output / Electric lock output
Input
Exit push button / Door monitor / Security sensor
Power Voltage
DC 12V
User Capacity
2000 (PP-87VX series: 32000)
IP Rating
IP54
Frequency
125 KHz ASK(PP-87P-6D-K) / 125 KHz ASK(PP-87N-6D-K) / 13.56 MHz(PP-87/M0-6D-K)
Material
ABS
Download
※ The specifications listed are subject to change by the company. If they differ from the actual product, the actual product shall prevail.
